Test Records A-3 MS2027C VNA Master Test Record
MS20xxC MM PN: 10580-00307 Rev. D A-3
Instrument Information
A-3 MS2027C VNA Master Test Record
VNA Frequency Accuracy – MS2027C
VNA Transmission Dynamic Range – MS2027C
_____ Attached Test Data Report
VNA S-Parameter Measurements Verification – MS2027C
_____ Attached Verification Report
Power Monitor Measurement Accuracy (For instruments with Option 5) – MS2027C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-3. VNA Frequency Accuracy
VNA Output Frequency Specification Frequency Counter Reading
2.6 GHz ±3.9 kHz kHz
Table A-4. Power Monitor Measurement Accuracy
Power Level @ 1 GHz Specification Measured Value
+13 dBm ±1 dB dBm
0 dBm ±1 dB dBm
–7 dBm ±1 dB dBm
–21 dBm ±1 dB dBm
–40 dBm ±1 dB dBm
