Test Records A-5 MS2036C VNA Master Test Record

MS20xxC MM PN: 10580-00307 Rev. D A-9

Instrument Information

Spectrum Analyzer Resolution Bandwidth Accuracy – MS2036C

Serial Number: Firmware Revision: Operator:

Options: Date:

Table A-17. Spectrum Analyzer Resolution Bandwidth Accuracy

RBW Span VBW Lower Limit Measured Values Upper Limit

10MHz 20MHz 1MHz 9MHz MHz 11MHz

3MHz 6MHz 300kHz 2.7MHz MHz 3.3MHz

1MHz 2MHz 100kHz 0.9MHz MHz 1.1MHz

300 kHz 600 kHz 30 kHz 270 kHz kHz 330 kHz

100kHz 200kHz 10kHz 90kHz kHz 110kHz

30 kHz 60 kHz 3 kHz 27 kHz kHz 33 kHz

10kHz 20kHz 1kHz 9kHz kHz 11kHz

3kHz 6kHz 300Hz 2.7kHz kHz 3.3kHz

1kHz 2kHz 100Hz 0.9kHz kHz 1.1kHz

300 Hz 600 Hz 30 Hz 270 Hz Hz 330 Hz

100 Hz 200 Hz 10 Hz 90 Hz Hz 110 Hz

30Hz 60Hz 3Hz 27Hz Hz 33Hz

10 Hz 20 Hz 3 Hz 9 Hz Hz 11 Hz

3Hz 10Hz 1Hz 2.7Hz Hz 3.3Hz

1 Hz 2 Hz 1 Hz 0.9 Hz Hz 1.1 Hz
