Test Records A-6 MS2037C VNA Master Test Record
MS20xxC MM PN: 10580-00307 Rev. D A-17
Instrument Information
Spectrum Analyzer Residual Spurious Response – MS2037C (continued)
Spectrum Analyzer Displayed Average Noise Level (DANL) – MS2037C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-30. Spectrum Analyzer Residual Spurious Response with Preamp On
Start Freq Stop Freq RBW VBW Specification Measured Values
1 MHz 30 MHz 3 kHz 300 Hz ≤ –100 dBm dBm
30 MHz 9 GHz 3 kHz 300 Hz ≤ –100 dBm dBm
9GHz 13GHz 10kHz 1kHz ≤ –100 dBm dBm
13 GHz 15 GHz 10 kHz 1 kHz ≤ –100 dBm dBm
Table A-31. Spectrum Analyzer DANL with Preamp Off
Start Freq Stop Freq RBW VBW Specification
Measured Value
(100 kHz RBW)
Calculated Value
(1 Hz RBW)
10 MHz 4 GHz 100 kHz 1 kHz ≤ –141 dBm dBm dBm
4GHz 9GHz 100kHz 1kHz ≤ –134 dBm dBm dBm
9 GHz 13 GHz 100 kHz 1 kHz ≤ –129 dBm dBm dBm
13GHz 15GHz 100kHz 1kHz ≤ –123 dBm dBm dBm
Table A-32. Spectrum Analyzer DANL with Preamp On
Start Freq Stop Freq RBW VBW Specification
Measured Value
(100 kHz RBW)
Calculated Value
(1 Hz RBW)
10 MHz 4 GHz 100 kHz 1 kHz ≤ –160 dBm dBm dBm
4GHz 9GHz 100kHz 1kHz ≤ –156 dBm dBm dBm
9 GHz 13 GHz 100 kHz 1 kHz ≤ –152 dBm dBm dBm
13GHz 15GHz 100kHz 1kHz ≤ –145 dBm dBm dBm
