Anritsu VNA Master MS2026C Maintenance Manual

A-6 MS2037C VNA Master Test Record Test Records
A-20 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Amplitude Accuracy – MS2037C
Serial Number: Firmware Revision: Operator:
Options: Date:
Note
The listed Amplitude Accuracy specifications apply when the instrument is being verified in an
environment between 20°C and 30°C after a 30 minute warm-up. For an instrument that is not being
verified in a temperature controlled environment but within a temperature range between –10°C and
50°C and after a 60 minute warm-up, add ± 1 dB to the Amplitude Accuracy specification.
Table A-39. Spectrum Analyzer 50 MHz Amplitude Accuracy Setup Table
Test Power Level @ 50 MHz Required Sensor B Reading
0dBm dBm
–4 dBm dBm
–10 dBm dBm
–14 dBm dBm
–20 dBm dBm
–24 dBm dBm
–30 dBm dBm
–34 dBm dBm
–40 dBm dBm
–44 dBm dBm
–50 dBm dBm
Table A-40. Spectrum Analyzer 50 MHz Amplitude Accuracy
Test Power Specification Reference Level Atten Lvl Measured Value Deviation
0 dBm ±1.3 dB 10 dBm 30 dB dBm dB
–4 dBm ±1.3 dB 10 dBm 30 dB dBm dB
–10dBm ±1.3dB 0dBm 20dB dBm dB
–14dBm ±1.3dB 0dBm 20dB dBm dB
–20 dBm ±1.3 dB –10 dBm 10 dB dBm dB
–24 dBm ±1.3 dB –10 dBm 10 dB dBm dB
–30dBm ±1.3dB –20dBm 0dB dBm dB
–34dBm ±1.3dB –20dBm 0dB dBm dB
–40dBm ±1.3dB –30dBm 0dB dBm dB
–44dBm ±1.3dB –30dBm 0dB dBm dB
–50dBm ±1.3dB –40dBm 0dB dBm dB
