Test Records A-7 MS2038C VNA Master Test Record
MS20xxC MM PN: 10580-00307 Rev. D A-29
Instrument Information
Spectrum Analyzer Residual Spurious Response – MS2038C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-53. Spectrum Analyzer Residual Spurious Response with Preamp Off
Start Freq Stop Freq RBW VBW Specification Measured Values
9kHz 100kHz 300Hz 10Hz ≤ –90 dBm dBm
100 kHz 30 MHz 1 kHz 100 Hz ≤ –90 dBm dBm
30MHz 5.35GHz 3kHz 3kHz ≤ –90 dBm dBm
5.35 GHz 9 GHz 3 kHz 100 Hz ≤ –90 dBm dBm
9GHz 11.11GHz 1kHz 100Hz ≤ –90 dBm dBm
11.11 GHz 13 GHz 3 kHz 300 Hz ≤ –90 dBm dBm
13GHz 16.5GHz 1kHz 300Hz ≤ –85 dBm dBm
16.5 GHz 20 GHz 300 Hz 100 Hz ≤ –85 dBm dBm
