Anritsu VNA Master MS2026C Maintenance Manual

A-5 MS2036C VNA Master Test Record Test Records
A-14 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Amplitude Accuracy – MS2036C (continued)
Spectrum Analyzer Third Order Intercept – MS2036C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-26. Spectrum Analyzer Amplitude Accuracy Across Frequency – 8000 MHz and 8999 MHz
Freq
(MHz)
Test
Power
(dBm)
Atten
Level
(dB)
Spec
(dB)
Marker
M1
Reading
(dBm)
Dev
(dB)
Freq
(MHz)
Test
Power
(dBm)
Atten
Level
(dB)
Spec
(dB)
Marker
M1
Reading
(dBm)
Dev
(dB)
8000
–30 0 ±1.3
8999
–30 0 ±1.3
–305±1.3 –305±1.3
–30 10 ±1.3 –30 10 ±1.3
–30 20 ±1.3 –30 20 ±1.3
–2 30 ±1.3 –2 30 ±1.3
–2 40 ±1.3 –2 40 ±1.3
–2 50 ±1.3 –2 50 ±1.3
–2 60 ±1.3 –2 60 ±1.3
Table A-27. Spectrum Analyzer Third Order Intercept
Frequency Specification Marker Reading Calculated TOI
2399.851 MHz dBm
2400.151 MHz dBm
2400 MHz ≥ +15 dBm dBm
