A-2 MS2026C VNA Master Test Record Test Records
A-2 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
A-2 MS2026C VNA Master Test Record
VNA Frequency Accuracy – MS2026C
VNA Transmission Dynamic Range – MS2026C
_____ Attached Test Data Report
VNA S-Parameter Measurements Verification – MS2026C
_____ Attached Verification Report
Power Monitor Measurement Accuracy (For instruments with Option 5) – MS2026C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-1. VNA Frequency Accuracy
VNA Output Frequency Specification Frequency Counter Reading
2.6 GHz ± 3.9 kHz kHz
Table A-2. Power Monitor Measurement Accuracy
Power Level @ 1 GHz Specification Measured Value
+13 dBm ±1 dB dBm
0 dBm ±1 dB dBm
–7 dBm ±1 dB dBm
–21 dBm ±1 dB dBm
–40 dBm ±1 dB dBm
To Next Page
