Anritsu VNA Master MS2026C Maintenance Manual

A-7 MS2038C VNA Master Test Record Test Records
A-30 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Residual Spurious Response – MS2038C (continued)
Spectrum Analyzer Displayed Average Noise Level (DANL) – MS2038C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-54. Spectrum Analyzer Residual Spurious Response with Preamp On
Start Freq Stop Freq RBW VBW Specification Measured Values
1 MHz 30 MHz 3 kHz 300 Hz ≤ –100 dBm dBm
30 MHz 9 GHz 3 kHz 300 Hz ≤ –100 dBm dBm
9GHz 13GHz 10kHz 1kHz ≤ –100 dBm dBm
13 GHz 16.5 GHz 10 kHz 1 kHz ≤ –100 dBm dBm
16.5 GHz 20 GHz 1 kHz 100 Hz ≤ –100 dBm dBm
Table A-55. Spectrum Analyzer DANL with Preamp Off
Start Freq Stop Freq RBW VBW Specification
Measured Value
(100 kHz RBW)
Calculated Value
(1 Hz RBW)
10 MHz 4 GHz 100 kHz 1 kHz ≤ –141 dBm dBm dBm
4 GHz 9 GHz 100 kHz 1 kHz ≤ –134 dBm dBm dBm
9 GHz 13 GHz 100 kHz 1 kHz ≤ –129 dBm dBm dBm
13 GHz 20 GHz 100 kHz 1 kHz ≤ –123 dBm dBm dBm
Table A-56. Spectrum Analyzer DANL with Preamp On
Start Freq Stop Freq RBW VBW Specification
Measured Value
(100 kHz RBW)
Calculated Value
(1 Hz RBW)
10 MHz 4 GHz 100 kHz 1 kHz ≤ –160 dBm dBm dBm
4 GHz 9 GHz 100 kHz 1 kHz ≤ –156 dBm dBm dBm
9 GHz 13 GHz 100 kHz 1 kHz ≤ –152 dBm dBm dBm
13 GHz 20 GHz 100 kHz 1 kHz ≤ –145 dBm dBm dBm
