MS20xxC MM PN: 10580-00307 Rev. D 5-1
Chapter 5 — Battery Information and
Replacement
5-1 Introduction
This chapter describes the removal and replacement procedures for the instrument battery. Illustrations
(drawings or photographs) is this manual may differ slightly from the instrument that you are servicing, but
the basic removal and replacement functions will remain as specified. The illustrations are meant to provide
assistance with identifying parts and their locations.
5-2 Replaceable Parts and Assemblies
The following replaceable parts are related to the battery pack and power adapters. To ensure that the correct
parts are provided, be sure to list the model number, the instrument serial number, and the installed options
with the order. The installed options are listed on a label on the top of the VNA Master and can also be viewed
in the System / Status display.
5-3 Battery Information
The following general information relates to the care and handling of the MS202xC or MS203xC VNA Master
Rechargeable Lithium-Ion Battery.
Approved Batteries Only
• Always use the battery only for its intended purpose.
• Use only Anritsu-approved battery packs. Some non-approved battery packs may fit into the
VNA Master but are electrically incompatible and will not charge correctly.
• The battery can be charged and discharged hundreds of times, but it will eventually wear out.
• The battery may need to be replaced when the operating time between charging becomes noticeably
shorter than normal.
• Never use a damaged or worn out charger or battery.
Table 5-1. Replaceable Battery Parts and Assemblies
Part Number Description
61379-2
Battery Door
– For all MS202xC instruments
3-67151-2
Battery Door
– For all MS203xC instruments
40-187-R AC to DC Power Adapter
633-44 Rechargeable Battery, Li-Ion
633-75 Rechargeable High Capacity Battery, Li-Ion
806-141 Automotive 12 Volt DC Adapter
