A-6 MS2037C VNA Master Test Record Test Records
A-18 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Frequency Accuracy – MS2037C
Spectrum Analyzer Frequency Accuracy (Option 31, GPS) – MS2037C
Spectrum Analyzer Single Side Band (SSB) Phase Noise – MS2037C
Spectrum Analyzer Spurious Response (Second Harmonic Distortion) – MS2037C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-33. Spectrum Analyzer Frequency Accuracy
Frequency Specification Measured Value Deviation
1 GHz ± 1.3 kHz GHz kHz
7 GHz ± 9.1 kHz GHz kHz
Table A-34. Spectrum Analyzer Frequency Accuracy with GPS On
Frequency Specification Measured Value Deviation
7 GHz < ± 350 Hz GHz Hz
Table A-35. Spectrum Analyzer SSB Phase Noise
Offset Frequency Specification Measured Value Calculated Value
10 kHz ≤ –100 dBc/Hz dB dBc/Hz
100 kHz ≤ –102 dBc/Hz dB dBc/Hz
1MHz ≤ –107 dBc/Hz dB dBc/Hz
10 MHz ≤ –120 dBc/Hz dB dBc/Hz
Table A-36. Spectrum Analyzer Spurious Response (Second Harmonic Distortion)
Frequency Specification Measured Value 2nd Harmonic Level
50.1 MHz dBm
100.2 MHz ≤ –54 dBc dBm dBc
To Next Page
