A-5 MS2036C VNA Master Test Record Test Records
A-8 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Single Side Band (SSB) Phase Noise – MS2036C
Spectrum Analyzer Spurious Response (Second Harmonic Distortion) – MS2036C
Spectrum Analyzer Input Related Spurious (IRS) Signals – MS2036C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-14. Spectrum Analyzer SSB Phase Noise
Offset Frequency Specification Measured Value Calculated Value
10 kHz ≤ –100 dBc/Hz dB dBc/Hz
100 kHz ≤ – 102 dBc/Hz dB dBc/Hz
1MHz ≤ –107 dBc/Hz dB dBc/Hz
10 MHz ≤ – 120 dBc/Hz dB dBc/Hz
Table A-15. Spectrum Analyzer Spurious Response (Second Harmonic Distortion)
Frequency Specification Measured Value 2nd Harmonic Level
50.1 MHz dBm
100.2 MHz ≤ –54dBc dBm dBc
Table A-16. Spectrum Analyzer Input Related Spurious (IRS) Signals
Frequency Specification Measured Value Calculated IRS
1000 MHz dBm
719 MHz to 721 MHz ≤ –60dBc dBm dBc
3273 MHz dBm
2423 MHz to 3271 MHz ≤ –60dBc dBm dBc
3275 MHz to 4123 MHz ≤ –60dBc dBm dBc
8000 MHz dBm
7719 MHz to 7721 MHz ≤ –60dBc dBm dBc
