Test Records A-7 MS2038C VNA Master Test Record
MS20xxC MM PN: 10580-00307 Rev. D A-33
Instrument Information
Spectrum Analyzer Amplitude Accuracy – MS2038C
Serial Number: Firmware Revision: Operator:
Options: Date:
Note
The listed Amplitude Accuracy specifications apply when the instrument is being verified in an
environment between 20°C and 30°C after a 30 minute warm-up. For an instrument that is not being
verified in a temperature controlled environment but within a temperature range between –10°C and
50°C and after a 60 minute warm-up, add ± 1 dB to the Amplitude Accuracy specification.
Table A-63. Spectrum Analyzer 50 MHz Amplitude Accuracy Setup Table
Test Power Level @ 50 MHz Required Sensor B Reading
0dBm dBm
–4 dBm dBm
–10 dBm dBm
–14 dBm dBm
–20 dBm dBm
–24 dBm dBm
–30 dBm dBm
–34 dBm dBm
–40 dBm dBm
–44 dBm dBm
–50 dBm dBm
Table A-64. Spectrum Analyzer 50 MHz Amplitude Accuracy
Test Power Specification Reference Level Atten Lvl Measured Value Deviation
0 dBm ±1.3 dB 10 dBm 30 dB dBm dB
–4 dBm ±1.3 dB 10 dBm 30 dB dBm dB
–10 dBm ±1.3 dB 0 dBm 20 dB dBm dB
–14 dBm ±1.3 dB 0 dBm 20 dB dBm dB
–20 dBm ±1.3 dB –10 dBm 10 dB dBm dB
–24 dBm ±1.3 dB –10 dBm 10 dB dBm dB
–30dBm ±1.3dB –20dBm 0dB dBm dB
–34dBm ±1.3dB –20dBm 0dB dBm dB
–40dBm ±1.3dB –30dBm 0dB dBm dB
–44dBm ±1.3dB –30dBm 0dB dBm dB
–50dBm ±1.3dB –40dBm 0dB dBm dB
