General Information 1-4 Options
MS20xxC MM PN: 10580-00307 Rev. D 1-3
1-4 Options
1-5 Anritsu Customer Service Centers
For the latest service and sales information in your area, please visit the following URL:
http://www.anritsu.com/contact.asp
Choose a country for regional contact information.
1-6 Recommended Test Equipment
The following test equipment is recommended for use in testing and maintaining the VNA Master.
Table 1-3. Option Numbers and Descriptions
Option Number Option Description
Option 2 Time Domain Analysis (Includes Distance Domain functionality)
Option 5 Power Monitor (requires external detector, MS2026C, MS2027C and MS2028C Only)
Option 7 Secure Data Operation
Option 10 Built-in Variable Bias-Tee (+12 V to +32 V in 0.1 V steps)
Option 11 K(f) Test Port Connectors (MS2028C and MS2038C Only)
Option 15 Vector Voltmeter
Option 19 High Accuracy Power Meter (requires external USB Sensor)
Option 25 Interference Analysis (MS2036C, MS2037C and MS2038C Only)
Option 27 Channel Scanner (MS2036C, MS2037C and MS2038C Only)
Option 31 GPS Receiver (requires GPS antenna, 2000-1528-R, sold separately)
Option 77 Balanced/Differential S-parameters, 1-Port
Option 501 Distance Domain (Do not order concurrently with Option 2)
Option 509 AM/FM/PM Demodulation Analyzer (MS2036C, MS2037C and MS2038C Only)
Table 1-4. Recommended Test Equipment for Vector Network Analyzer Verification (1 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
Frequency Counter
Frequency: 2 GHz to 3 GHz Anritsu Model MF2412B or
MF2412C
Frequency Reference
Frequency: 10 MHz Symmetricom Model
RubiSource T&M
Open/Short/Load
Frequency: DC to 18 GHz
Connector: N(m)
Anritsu Model OSLN50
Open/Short/Load
Frequency: DC to 18 GHz
Connector: N(f)
Anritsu Model OSLNF50
RF Coaxial Cable
Frequency: DC to 18 GHz
Impedance: 50 ohm
Connector: N(m) to N(m)
Anritsu Model 3670NN50-2
Verification Kit
Connector: N Type Anritsu Model SC7858
(Includes 2300-533-R software)
To Next Page
