Anritsu VNA Master MS2026C Maintenance Manual

1-6 Recommended Test Equipment General Information
1-4 PN: 10580-00307 Rev. D MS20xxC MM
Torque Wrench
3/4 in. (0.75 in.) Open End Wrench
12 lbf·in (1.35 N·m)
Anritsu Model 01-200
Open/Short/Load
(for Option 11)
Frequency: DC to 20 GHz
Connector: K(m)
Anritsu Model OSLK50
Open/Short/Load
(for Option 11)
Frequency: DC to 20 GHz
Connector: K(f)
Anritsu Model OSLKF50
RF Coaxial Cable
(for Option 11)
Frequency: DC to 40 GHz
Impedance: 50 ohm
Connector: K(f) to K(m)
Anritsu Model 3670K50-2
Verification Kit
(for Option 11)
Connector: K Type Anritsu Model SC7859
(includes 2300-533-R software)
Adapter
(for Option 11)
Frequency: DC to 40 GHz
Connector: K(m) to K(m)
Anritsu Model 33KK50B
Adapter
(for Option 11)
Frequency: DC to 18 GHz
Connector: N(f) to K(m)
Anritsu Model 34NFK50
Torque Wrench
(for Option 11)
5/16 in. (0.325 in.)
Open End Wrench
8 lbf·in (0.90 N·m)
Anritsu Model 01-201
Personal Computer
Operating System: Windows XP
Interface: Ethernet, RJ-48
Software: National Instruments
VISA version 4.4.1 or later
Any
System Verification Software Anritsu Part Number 2300-533-R
Test Software Anritsu Part Number 2300-535
Table 1-4. Recommended Test Equipment for Vector Network Analyzer Verification (2 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
