Anritsu VNA Master MS2026C Maintenance Manual

General Information 1-6 Recommended Test Equipment
MS20xxC MM PN: 10580-00307 Rev. D 1-5
Table 1-5. Recommended Test Equipment for Spectrum Analyzer Verification - For MS203xC Only (1 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
Frequency Reference
Frequency: 10 MHz Symmetricom Model
RubiSource T&M
Synthesized Signal Generator
Frequency: 0.1 Hz to 20 GHz
Power Output: +16 dBm
Step attenuator installed
Anritsu Model MG3692B or
MG3692C with Options 2A, 4 and 22
(Quantity 2)
Power Meter Power Range: (–70 to +20) dBm Anritsu Model ML2438A
Power Sensor
Frequency: 100 kHz to 18 GHz
Power Range: –67 to +20 dBm
Anritsu Model SC7400
(Quantity 2)
Power Sensor
Frequency: 10 MHz to 18 GHz
Power Range: –67 to +20 dBm
Anritsu Model MA2442D
RF Coaxial Cable
Frequency: DC to 18 GHz
Impedance: 50 ohm
Connector: N(m) to N(m)
Anritsu Model 15NN50-1.0B
(Quantity 2)
Power Splitter
Frequency: DC to 18 GHz
Connector: N(f)
Aeroflex/Weinschel Model 1870A
Fixed Attenuator
Frequency: DC to 18 GHz
Attenuation: 10 dB
Aeroflex/Weinschel Model 44-10
Fixed Attenuator
Frequency: DC to 18 GHz
Attenuation: 2 dB
Aeroflex/Weinschel Model 44-2
(Quantity 2)
Fixed Attenuator
Frequency: DC to 18 GHz
Attenuation: 6 dB
Aeroflex/Weinschel Model 44-6
(Quantity 2)
Fixed Attenuator
Frequency: DC to 18 GHz
Attenuation: 20 dB
Aeroflex/Weinschel Model 44-20
(Quantity 2)
Adapter
Frequency: DC to 18 GHz
Connector: K(m) to N(f)
Anritsu Model 34RKNF50
(Quantity 2)
Adapter
Frequency: DC to 18 GHz
Connector: N(m) to N(m)
Anritsu Model 34NN50A
Tee Adapter BNC(m) to BNC(f)/BNC(f) Anritsu Part Number 3-2600-2
Low Pass Filter
Frequency: 50 MHz
Connector: N(m) to N(f)
Anritsu Part Number 1030-96
Termination
Frequency: DC to 18 GHz
Impedance: 50 ohm
Connector: N(m)
Anritsu Model 28N50-2
Coaxial Cable
Impedance: 50 ohm
Connector: BNC(m) to BNC(m)
Anritsu part number 2000-1627-R
(Quantity 3)
Power Sensor
(for Option 11)
Frequency: 100 kHz to 40 GHz
Power Range: –67 to +20 dBm
Anritsu Model SC7413
(Quantity 2)
RF Coaxial Cable
(for Option 11)
Frequency: DC to 20 GHz
Connector: K(m) to K(f)
Anritsu Model 15KKF50-1.0A
Power Splitter
(for Option 11)
Frequency: DC to 40 GHz
Connector: K Type
Anritsu Model K241C
Fixed Attenuator
(for Option 11)
Frequency: DC to 40 GHz
Connector: K Type
Anritsu Model 41KC-10
