1-6 Recommended Test Equipment General Information
1-6 PN: 10580-00307 Rev. D MS20xxC MM
Adapter
(for Option 11)
Frequency: DC to 18 GHz
Connector: N(f) to K(m)
Anritsu Model 34NFK50
Adapter
(for Option 11)
Frequency: DC to 40 GHz
Connector: K(m) to K(m)
Anritsu Model 33KK50B
Termination
(for Option 11)
Frequency: DC to 40 GHz
Impedance: 50 ohm
Connector: K(m)
Anritsu Model 28K50
Table 1-6. Recommended Test Equipment for Options Verification
Equipment Critical Specification
Recommended
Manufacturer/Model
Synthesized Signal Generator
(for Option 5)
Frequency: 1 GHz
Power Level: –40 dBm to +13 dBm
Anritsu Model MG3692B or
MG3692C with Options 2A and 4
(or 5)
RF Detector
(for Option 5)
Frequency: 10 MHz to 20 GHz Anritsu Model 560-7N50B
Adapter
(for Option 5)
Frequency: DC to 40 GHz
Connector: K(m) to N(f)
Anritsu Model 34RKNF50
Power Meter
(for Option 5)
Power Range: (–70 to +20) dBm Anritsu Dual Channel Model
ML2438A
Power Sensor
(for Option 5)
Frequency: 10 MHz to 18 GHz,
Range: –67 to +20 dB
Anritsu Model MA2442D
Power Splitter
(for Option 5)
Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
Load Test Fixture
(for Option 10)
Resistance: 40 ohm
Power: 5 Watts
Anritsu Model T2904
Load Test Fixture
(for Option 10)
Resistance: 105 ohm
Power: 1 watt
Anritsu Model T3377
Load Test Fixture
(for Option 10)
Resistance: 78 ohm
Power: 20 Watts
Anritsu Model T3536
GPS Antenna
(for Option 31)
Connector: SMA male
Bias: 3 V or 5 V
Anritsu Part Number 2000-1528-R
or
Trimble Part Number 57861-00
[TNC(f) to SMA(m) Adapter
required]
Adapter
(for Option 31)
Connector: SMA(m) to BNC(f) Pomona Part Number 4290
Terminator
(for Option 31)
Connector: BNC(m)
Impedance: 93 ohm
Amphenol Part Number
B1004A1-ND3G-93R-0.05-1W
Table 1-5. Recommended Test Equipment for Spectrum Analyzer Verification - For MS203xC Only (2 of 2)
Equipment Critical Specification
Recommended
Manufacturer/Model
