Anritsu VNA Master MS2026C - Spectrum Analyzer Residual Spurious Response - MS2036 C

A-5 MS2036C VNA Master Test Record Test Records
A-6 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Residual Spurious Response – MS2036C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-8. Spectrum Analyzer Residual Spurious Response with Preamp Off
Start Freq Stop Freq RBW VBW Specification Measured Values
9 kHz 100 kHz 300 Hz 10 Hz ≤ –90dBm dBm
100 kHz 30 MHz 1 kHz 100 Hz ≤ –90dBm dBm
30 GHz 5.35 GHz 3 kHz 300 Hz ≤ –90dBm dBm
5.35 GHz 9 GHz 3 kHz 100 Hz ≤ –90dBm dBm
Table A-9. Spectrum Analyzer Residual Spurious Response with Preamp On
Start Freq Stop Freq RBW VBW Specification Measured Values
1 MHz 30 MHz 3 kHz 300 Hz ≤ – 100 dBm dBm
30 GHz 9 GHz 3 kHz 300 Hz ≤ – 100 dBm dBm
