A-7 MS2038C VNA Master Test Record Test Records
A-32 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Input Related Spurious (IRS) Signals – MS2038C
Spectrum Analyzer Resolution Bandwidth Accuracy – MS2038C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-61. Spectrum Analyzer Input Related Spurious (IRS) Signals
Frequency Specification Measured Values Calculated IRS
1000 MHz dBm
719 MHz to 721 MHz ≤ –60 dBc dBm dBc
3273 MHz dBm
2423 MHz to 3271 MHz ≤ –60 dBc dBm dBc
3275 MHz to 4123 MHz ≤ –60 dBc dBm dBc
8000 MHz dBm
7719 MHz to 7721 MHz ≤ –60 dBc dBm dBc
15000 MHz dBm
14719 MHz to 14721 MHz ≤ –60 dBc dBm dBc
Table A-62. Spectrum Analyzer Resolution Bandwidth Accuracy
RBW Span VBW Lower Limit Measured Values Upper Limit
10MHz 20MHz 1MHz 9MHz MHz 11MHz
3 MHz 6 MHz 300 kHz 2.7 MHz MHz 3.3 MHz
1 MHz 2 MHz 100 kHz 0.9 MHz MHz 1.1 MHz
300 kHz 600 kHz 30 kHz 270 kHz kHz 330 kHz
100kHz 200kHz 10kHz 90kHz kHz 110kHz
30 kHz 60 kHz 3 kHz 27 kHz kHz 33 kHz
10kHz 20kHz 1kHz 9kHz kHz 11kHz
3kHz 6kHz 300Hz 2.7kHz kHz 3.3kHz
1kHz 2kHz 100Hz 0.9kHz kHz 1.1kHz
300 Hz 600 Hz 30 Hz 270 Hz Hz 330 Hz
100 Hz 200 Hz 10 Hz 90 Hz Hz 110 Hz
30Hz60Hz 3Hz27Hz Hz33Hz
10 Hz 20 Hz 3 Hz 9 Hz Hz 11 Hz
3Hz 10Hz 1Hz 2.7Hz Hz 3.3Hz
1Hz 2Hz 1Hz 0.9Hz Hz 1.1Hz
