7-9 Internal Anatomy of the VNA Master MS2037C and MS2038C Assembly Removal and Replacement,

7-10 PN: 10580-00307 Rev. D MS20xxC MM

MS203xC Case and Back Screws

1. Battery

2. Case Back screw (1 of 4)

3. Recess for serial number label (serial number of SPA PCB)

4. Case Back screw (1 of 4)

5. Case Back screw (1 of 4)

6. Screws (4) to hold SPA RF In connector mounting plate to top connector panel

7. SPA RF In port (supplied with SPA PCB)

8. Case Back screw (1 of 4)

Figure 7-8. Case for MS203xC
