A-6 MS2037C VNA Master Test Record Test Records
A-16 PN: 10580-00307 Rev. D MS20xxC MM
Instrument Information
Spectrum Analyzer Residual Spurious Response – MS2037C
Serial Number: Firmware Revision: Operator:
Options: Date:
Table A-29. Spectrum Analyzer Residual Spurious Response with Preamp Off
Start Freq Stop Freq RBW VBW Specification Measured Values
9 kHz 100 kHz 300 Hz 10 Hz ≤ –90 dBm dBm
100 kHz 30 MHz 1 kHz 100 Hz ≤ –90 dBm dBm
30 MHz 5.35 GHz 3 kHz 300 Hz ≤ –90 dBm dBm
5.35 GHz 9 GHz 3 kHz 100 Hz ≤ –90 dBm dBm
9 GHz 11.11 GHz 1 kHz 100 Hz ≤ –90 dBm dBm
11.11 GHz 13 GHz 3 kHz 300 Hz ≤ –90 dBm dBm
13 GHz 15 GHz 1 kHz 300 Hz ≤ –85 dBm dBm
