Anritsu VNA Master MS2026C - T3377 Test Fixture Schematic

B-3 T3377 Test Fixture Schematic Test Fixture Schematics
B-2 PN: 10580-00307 Rev. D MS20xxC MM
B-3 T3377 Test Fixture Schematic
Figure B-2. T3377 Test Fixture Schematic
130-200-3
200, 5%, 3.25 W
130-200-3
200, 5%, 3.25 W
101-10-5
10, 5%, 0.25 W
513-32
101-10-5
10, 5%, 0.25 W
