Anritsu VNA Master MS2026C Maintenance Manual

General Information 1-9 Performance Verification Procedures
MS20xxC MM PN: 10580-00307 Rev. D 1-13
1-9 Performance Verification Procedures
Performance verification procedures are in the following Chapters:
• Chapter 2, “Vector Network Analyzer Performance Verification”
• Chapter 3, “Spectrum Analyzer Performance Verification”
• Chapter 4, “Options Performance Verification”
Refer to Table 1-8 for the list of performance verification procedures that are required for each instrument
model. Perform all of the procedures with an “x” in the Std column. Also perform the procedures with a “x” in
the Opt 5, Opt 10 and Opt 31 columns when these options are installed in the instrument.
Table 1-8. Required Performance Verification Procedures for each model of VNA Master (1 of 3)
Model Performance Verification Procedure Std
Opt
5
Opt
10
Opt
31
Procedure
Sections
MS2026C
VNA Frequency Accuracy x 2-2 on page 2-1
VNA Transmission Dynamic Range x 2-3 on page 2-3
VNA S-Parameters Measurements Accuracy x 2-4 on page 2-6
Power Monitor Measurement Accuracy x 4-2 on page 4-1
VNA Bias Tee Operational Check x 4-3 on page 4-4
GPS Operational Check x 4-4 on page 4-6
MS2027C
VNA Frequency Accuracy x 2-2 on page 2-1
VNA Transmission Dynamic Range x 2-3 on page 2-3
VNA S-Parameters Measurements Accuracy x 2-4 on page 2-6
Power Monitor Measurement Accuracy x 4-2 on page 4-1
VNA Bias Tee Operational Check x 4-3 on page 4-4
GPS Operational Check x 4-4 on page 4-6
MS2028C
VNA Frequency Accuracy x 2-2 on page 2-1
VNA Transmission Dynamic Range x 2-3 on page 2-3
VNA S-Parameters Measurements Accuracy x 2-4 on page 2-6
Power Monitor Measurement Accuracy x 4-2 on page 4-1
VNA Bias Tee Operational Check x 4-3 on page 4-4
GPS Operational Check x 4-4 on page 4-6
