1-9 Performance Verification Procedures General Information
1-14 PN: 10580-00307 Rev. D MS20xxC MM
MS2036C
VNA Frequency Accuracy x 2-2 on page 2-1
VNA Transmission Dynamic Range x 2-3 on page 2-3
VNA S-Parameters Measurements Accuracy x 2-4 on page 2-6
VNA Bias Tee Operational Check x 4-3 on page 4-4
GPS Operational Check x 4-4 on page 4-6
Spectrum Analyzer Residual Spurious Response x 3-2 on page 3-1
Spectrum Analyzer Displayed Average Noise Level
(DANL)
x 3-3 on page 3-4
Spectrum Analyzer Frequency Accuracy x 3-4 on page 3-6
Spectrum Analyzer Frequency Accuracy with GPS On x 4-5 on page 4-8
Spectrum Analyzer Single Side Band (SSB) Phase
Noise
x 3-5 on page 3-8
Spectrum Analyzer Spurious Response (Second
Harmonic Distortion)
x 3-6 on page 3-11
Spectrum Analyzer Input Related Spurious (IRS)
Signals
x 3-7 on page 3-14
Spectrum Analyzer Resolution Bandwidth Accuracy x 3-8 on page 3-19
Spectrum Analyzer Amplitude Accuracy x 3-9 on page 3-22
Spectrum Analyzer Third Order Intercept (TOI) x 3-10 on page 3-29
MS2037C
VNA Frequency Accuracy x 2-2 on page 2-1
VNA Transmission Dynamic Range x 2-3 on page 2-3
VNA S-Parameters Measurements Accuracy x 2-4 on page 2-6
VNA Bias Tee Operational Check x 4-3 on page 4-4
GPS Operational Check x 4-4 on page 4-6
Spectrum Analyzer Residual Spurious Response x 3-2 on page 3-1
Spectrum Analyzer Displayed Average Noise Level
(DANL)
x 3-3 on page 3-4
Spectrum Analyzer Frequency Accuracy x 3-4 on page 3-6
Spectrum Analyzer Frequency Accuracy with GPS On x 4-5 on page 4-8
Spectrum Analyzer Single Side Band (SSB) Phase
Noise
x 3-5 on page 3-8
Spectrum Analyzer Spurious Response (Second
Harmonic Distortion)
x 3-6 on page 3-11
Spectrum Analyzer Input Related Spurious (IRS)
Signals
x 3-7 on page 3-14
Spectrum Analyzer Resolution Bandwidth Accuracy x 3-8 on page 3-19
Spectrum Analyzer Amplitude Accuracy x 3-9 on page 3-22
Spectrum Analyzer Third Order Intercept (TOI) x 3-10 on page 3-29
Table 1-8. Required Performance Verification Procedures for each model of VNA Master (2 of 3)
Model Performance Verification Procedure Std
Opt
5
Opt
10
Opt
31
Procedure
Sections
To Next Page
