5-4 Battery Pack Removal and Replacement Battery Information and Replacement
5-4 PN: 10580-00307 Rev. D MS20xxC MM
2. Place a finger in the battery access door notch and push the door down towards the bottom of the
instrument, as shown in Figure 5-2, “Battery Access Door Notch”.
3. Remove the Battery Access Door, as shown in Figure 5-3, “Removing the Battery Access Door”.
4. The door may be reinstalled or replaced with a new door.
Figure 5-2. Battery Access Door Notch
Figure 5-3. Removing the Battery Access Door
Pull
Battery
Access
Door
Down
to
Remove
