7-11 Replacing Main Keypad Components – 3-61362, 3-71027-3 Assembly Removal and Replacement,
7-16 PN: 10580-00307 Rev. D MS20xxC MM
28. Work your way around the bezel gradually positioning each Locking Tab into its slot. Take care not to
bend any Locking Tab.
29. When all are correctly inserted, go around again snapping each tab into place.
30. When complete, each button should protrude approximately 1.5 mm to 2 mm above the bezel.
Installing Battery:
Refer to Section 5-4 “Battery Pack Removal and Replacement” on page 5-3.
31. Install the Battery.
32. Install the Battery Door.
Restarting the Instrument:
33. Restart the instrument.
34. Perform a function check for each button on the Main Keypad and the Main Menu Keypad.
