Options Performance Verification 4-4 GPS (Option 31) Operational Check
MS20xxC MM PN: 10580-00307 Rev. D 4-7
16. Press the Esc key to dismiss the GPS INFO dialog box.
17. Press the GPS On/Off soft key to turn Off GPS.
18. Remove the adapter and terminator from the GPS Antenna connector of the VNA Master.
GPS Receiver Operational Check (For MS2026C, MS2027C, and MS2028C Only)
19. Connect the GPS Antenna to the GPS Antenna connector on the VNA Master.
20. Press the GPS On/Off soft key to turn On GPS.
21. When the GPS fix is acquired, the GPS indicator at the top of the screen turns green.
22. Press the GPS Info soft key to view the latitude, longitude, altitude, and other GPS information.
Note
For the MS2036C, MS2037C, and MS2038C, go to Section 4-5 “Spectrum Analyzer Frequency
Accuracy with GPS On” on page 4-8.
Note
Ensure that the Anritsu GPS Antenna is in a direct line-of-sight relationship to the GPS satellites or
that the Antenna is placed outside without any obstructions.
Note
Acquiring satellites may take as long as three minutes. The GPS indicator turns green after at least
three satellites has been tracked by the GPS receiver.
