6-6 Main Keypad Bezel for VNA Master MS202xC Assembly Removal and Replacement, MS202xC
6-4 PN: 10580-00307 Rev. D MS20xxC MM
1. Main Keypad Bezel Front View
2. Top View
3. Side View
4. Left side locking tab locations
5. Right side locking tab locations
6. Three-Quarter View
7. Underlying Main Keypad Rubber Membrane
Figure 6-2. Main Keypad Bezel and Locking Tabs for MS202xC
