4. Insert the USB in one of the USB ports and wait for the upgrade confirmation window to show up.

5. Press Upgrade to initiate the upgrade process.

6. X1 will reboot automatically once the upgrade process is completed. Please go to Menu > Settings > About Printer

to confirm the firmware versions of printer and of printhead are both updated.

Printer Firmware Version

Printhead Firmware Version
