ANSER CODING INC. 20 X1 User Interface

1.4.1 Adding Message Objects

In X1 Message Editor, use Add Object  is highly recommended to start message editing. Press it and the Add

Object page appears as the figure below shows. Here you can see the most often-used objects are all included. Please

refer to the following sections for step-by-step instructions of adding objects into a message.

Figure 1-18. To Add Eight Types of Object
