ANSER CODING INC. 7 X1 User Interface

1.2.2 Assign a Print Station

After setting up a production line, the next step is to assign a print station which may be a single or union of two

printheads installed in a production line. Set this print station according to the physical installation and combination of

printhead(s). Please refer to the following table, figures and Section 1.5.2 for more details.

Table 1-1. Print Station and Printhead Combinations

Item

Description

Single Mode

A print station containing single ½ " or 1" printhead.

Stitch Mode

A print station composed of two ½ " or two 1" printheads stitching

together to achieve a larger message printing.

Parallel Mode

A print station composed of two ½ " or two 1" printheads installed

parallelly for non-stop printing.

Note: If the printhead(s) is not properly connected, neither the production line nor printing can be started.
