ANSER CODING INC. 64 X1 Printing Setup
2 X1 Printing Setup
Production Line Setup
Production line settings are the top layer of the X1 function structure (Please see Figure 1-61.), and they encapsulate
print stations and messages. It is required for having a production line created before setting up print stations and
selecting messages. Users can access directly from the homepage by pressing the quick access button  .
Users have the options  
backup settings.
To create a production line:
a.  button.
b.  o access production line configuration parameters.
c. Name the production line.
d. Production Line speed settings.
i. With Encoder: To enable encoder and to specify whether it is connected to controller or printhead.
ii. No Encoder: Input conveyor speed or use test option to detect current object speed by using a photocell
sensor and width of the object.
e. Select encoder DPI value according to encoder or input wheel pulse and diameter to calculate.
f. Press the Save button before proceeding to print station setup.
.
