ANSER CODING INC. 17 X1 User Interface

Getting to Know the Message Editor

X1 offers the possibility to create and edit messages directly in the controller. The X1 editor offers the necessary tools

to make message editing a more straightforward process.  

part of the message editor is marked by a red number in the following Figure 1-17 and is described in the following Table

1-4.

Figure 1-17. X1 Message Editor Page
