Anser X1 - 1.5.2.1.1 Print Station Delay; Figure 1-54. Print Station Delay

ANSER CODING INC. 44 X1 User Interface
1.5.2.1.1 Print Station Delay
Users must measure the distance from the sensor trigger point to the location of the product where message printing
starts, and the measurement should include the distance from sensor installation to the cartridge nozzle. The definition
of print station delay is the same as message delay, and the differences are: 1. Print station delay is set for all messages
with a default value while message delay is set for individual message with higher priority; 2. When no message delay is
set, X1 will use print station delay as message delay.
Figure 1-54. Print Station Delay
Note: The same delay value applies to all printing messages.
.
