Anser X1 - Printhead Settings

To Next Page

To Previous Page

ANSER CODING INC. 66 X1 Printing Setup

Printhead Settings

In the printhead, settings to define the type of cartridge to use in the station, vertical resolution, and options for repeat

printing can all be found. Likewise, pre-purge options can be configured to keep the nozzles moist when working in hot

and dry environments.

Access printhead Settings overview page,

a. Select the print station to configure the printhead settings.

b.  

c. Set resolution, repeat settings and pre-purge.

d. Press the Save button to save printhead settings.

Note: When using a half-inch printhead, select one of the nozzle rows or both for nozzle switching.
