ANSER CODING INC. 74 X1 Operation
Figure 3-2. Variable Input Sources
Table 3-1. Variable Input Methods
Variable Table
Variable Buffer
Excel Files
Methods to Edit
1. PC Software (Message Pro
X)
2. Controller UI
3. Net Protocol over Ethernet
(0xCA)
4. USB
1. Net Protocol over Ethernet
(0xCF, 0xCB, 0xCC)
1. PC Software (Message Pro
X)
Note
Variable source setup as
.
Variable source setup as
.
Variable source setup as
.
3.1.1 Internal Variable Table
There is a total of 100 variables that can be defined and kept in an X1 controller. Each of the variables can hold up to 100
alphabets (100 bytes). Message editor is full Unicode supported in UTF-8 format.
3.1.2 Excel Files or Database
Variable objects are able to take imported .csv file extensions as a source. When a print job starts, users have the option
to preview and choose which entry or row they would like to start.
.
