100 Technical Specifications and Operating Parameters
A.7.2 Weight
• 2.0 kg (4.4 lbs.) net. (Instrument)
• 2.2 kg (4.84 lbs.) net. (Antenna and Cable)
• 0.5 kg (1.1 lbs.) net. (Option 06)
• 8 kg (18 lbs.) includes antenna, cables, and accessories. (Shipping)
A.7.3 Power Requirements
The Model 1084A/B/C comes with one of three user-specified internal power supplies. Additionally,
the antenna receives power through the antenna cable connected to the Type F connector on the
rear panel.
• Option 07: 85 – 264 Vac, 47 – 440 Hz, or 110 – 370 Vdc, < 20 W typical (Standard power
supply)
• Option 08: 10 – 60 Vdc (DC only), < 20 W typical. Uses a three-position terminal strip in
place of the IEC-320 power inlet module; includes Surge-Withstand Capability
• Option 10: 110 – 350 Vdc, < 20 VA or 85 – 250 Vac, 47 – 440 Hz, with three-position Terminal
Power Strip and Surge-Withstand Capability
A.7.4 Power Connector
• Option 7, Standard Power Supply: This includes a fused IEC-320 power inlet module with
mating ac cord. Plug type specified as power cord options P1 through P10 (see Section 3.2.1).
• Options 08 and 10: Using a 3-pole terminal strip power inlet with Surge-Withstand Capability
(see Section 3.3 and 3.4).
A.7.5 Electro-Magnetic Interference (EMI)
• Conducted Emissions: power supply (Options 07 and 08) complies with FCC 20780, Class A
and VDE 0871/6.78, Class A
• Surge Withstand Capability (SWC), power inlet (Options 08 and 10) designed to meet
ANSI/IEEE C37.90-1 and IEC 801-4.
A.7.6 Temperature and Humidity
Temperature Operating Storage
Instrument 0 to 50
◦
C -40 to 75
◦
C
Antenna -40 to 85
◦
C -55 to 100
◦
C
Antenna Cable -40 to 75
◦
C -40 to 80
◦
C
Humidity 10 to 90% non-condensing 10 to 90% non-condensing
Table A.3: Temperature and Humidity List
