Arbiter Systems 1084A - Option 06, Connector Pin Designation

C.6 Option 06: Parallel BCD Output (1 millisecond Resolution) 117
C.6.5 Option 06, Connector Pin Designation
Pin No: BCD Mode Parallel Data Mode
Function/Bit Weighting: Function:
1 Ground Ground
2 1 PPS output Data Bit 47
*3 Output 4 (Dig. only) Data Bit 45
*4 Output 2 (Dig./An.) Data Bit 27
5 Day 200 Data Bit 35
6 Day 80 Data Bit 43
7 Day 20 Data Bit 41
8 Day 8 Data Bit 39
9 Day 2 Data Bit 37
10 20 Hr. Data Bit 33
11 8 Hr. Data Bit 31
12 2 Hr. Data Bit 29
13 40 Min. Data Bit 26
14 10 Min. Data Bit 24
15 4 Min. Data Bit 22
16 1 Min. Data Bit 20
17 20 Sec. Data Bit 17
18 8 Sec. Data Bit 15
19 2 Sec. Data Bit 13
20 800 mS Data Bit 11
21 200 mS Data Bit 9
22 80 mS Data Bit 7
23 20 mS Data Bit 5
24 8 mS Data Bit 3
25 2 mS Data Bit 1
26 Ground Ground
27 1 kPPS output Data Bit 46
*28 Output 3 (Dig. only) Data Bit 44
*29 Output 1 (Dig./An.) Data Bit 19
30 Day 100 Data Bit 34
31 Day 40 Data Bit 42
32 Day 10 Data Bit 40
33 Day 4 Data Bit 38
34 Day 1 Data Bit 36
35 10 Hr. Data Bit 32
36 4 Hr. Data Bit 30
37 1 Hr. Data Bit 28
38 20 Min. Data Bit 25
39 8 Min. Data Bit 23
40 2 Min. Data Bit 21
