Arbiter Systems 1084A User Manual

C.4 Option 03: Four Additional Outputs – Obsolete 111
Output Signal Function Select Jumper Mode Select Jumper
IRIG-B Modulation 1 C
Deviation 2 C
IRIG-B 3 A
IRIG-E 4 A
IRIG-H 5 A
10 MPPS 6 A
5 MPPS 7 A
1 MPPS 8 A
100 kPPS 9 A
10 kPPS 10 A
1 kPPS 11 A
100 PPS 12 A
60 PPS* 13 A
50 PPS* 14 A
10 PPS 15 A
IRIG-D/1 PPM 16 A
1 PPM 17 A
1 PPS 18 A
Programmable Pulse 19 A
Out of Lock 20 A
IRIG-B Mod. Manch. 21 A
No Connection 22 A
Table C.1: Output Connector Jumper Settings
*not available in Model 1084A/B/C
