Arbiter Systems 1084A User Manual

118 Options List
41 40 Sec. Data Bit 18 −
42 10 Sec. Data Bit 16 −
43 4 Sec. Data Bit 14 −
44 1 Sec. Data Bit 12 −
45 400 mS Data Bit 10 −
46 100 mS Data Bit 8 −
47 40 mS Data Bit 6 −
48 10 mS Data Bit 4 −
49 4 mS Data Bit 2 −
50 1 mS Data Bit 0 −
Table C.2: Option 06, Connector Pin Designation
*These pins can be configured for any of the listed functions, regardless of the main mode of
operation for Option 06.
Figure C.4: Option 06 Output Connector
