Arbiter Systems 1084A User Manual

132 Options List
C.10.5 Option 17, Connector Pin Designation
Pin No: BCD Mode Parallel Data Mode RS-232C
Function/Bit Weighting: Function: Function
1 Ground Ground Ground
2 1 PPS output Data Bit 47 −
*3 Output 4 (Dig. only) Data Bit 45 DTR
*4 Output 2 (Dig./An.) Data Bit 27 RXD
5 Day 200 Data Bit 35 −
6 Day 80 Data Bit 43 −
7 Day 20 Data Bit 41 −
8 Day 8 Data Bit 39 −
9 Day 2 Data Bit 37 −
10 20 Hr. Data Bit 33 −
11 8 Hr. Data Bit 31 −
12 2 Hr. Data Bit 29 −
13 40 Min. Data Bit 26 −
14 10 Min. Data Bit 24 −
15 4 Min. Data Bit 22 −
16 1 Min. Data Bit 20 −
17 20 Sec. Data Bit 17 −
18 8 Sec. Data Bit 15 −
19 2 Sec. Data Bit 13 −
20 800 mS Data Bit 11 −
21 200 mS Data Bit 9 −
22 80 mS Data Bit 7 −
23 20 mS Data Bit 5 −
24 8 mS Data Bit 3 −
25 2 mS Data Bit 1 −
26 Ground Ground Ground
27 1 kPPS output Data Bit 46 −
*28 Output 3 (Dig. only) Data Bit 44 DSR
*29 Output 1 (Dig./An.) Data Bit 19 TXD
30 Day 100 Data Bit 34 −
31 Day 40 Data Bit 42 −
32 Day 10 Data Bit 40 −
33 Day 4 Data Bit 38 −
34 Day 1 Data Bit 36 −
35 10 Hr. Data Bit 32 −
36 4 Hr. Data Bit 30 −
37 1 Hr. Data Bit 28 −
38 20 Min. Data Bit 25 −
39 8 Min. Data Bit 23 −
40 2 Min. Data Bit 21 −
Table C.3: Option 17, Connector Pin Designation
Note: Table C.3 continued on next page.
