Arbiter Systems 1084A User Manual

142 Options List
Output Transmitter Jumper Pin Signal Notes
CR1 JMP2 1 IRIG-B 1, 2, 3
CR2 JMP3 2 IRIG-E 2, 3
CR3 JMP4 3 IRIG-H 2, 3
CR4 JMP5 4 10 MPPS 2, 3
– – 5 5 MPPS 2, 3
– – 6 1 MPPS 2, 3
– – 7 100 kPPS 2, 3
– – 8 10 kPPS 2, 3
– – 9 1 kPPS 2, 3
– – 10 100 PPS 2, 3
– – 11 60 PPS 2
– – 12 50 PPS 2
– – 13 10 PPS 2, 3
– – 14 1 PPM 2, 3
– – 15 1 PPH 2, 3
– – 16 1 PPS 1, 2, 3
– – 17 Prog. Pulse 1, 2, 3
– – 18 IRIG-B Mod. Manch. 2, 3
Table C.5: Option 20A, Four Fiber Optic Output Configuration
1. Signals available on the Model 1093A/B/C
2. Signals available on the Model 1088A/B
3. Signals available on the Model 1084A/B/C
