Arbiter Systems 1084A User Manual

C.14 Option 23, COMTRADE Sample Rate Generator 149
Output Signal Function Jumpers Mode Jumpers
IRIG-B Modulated, 10 Vpp 1 C
Deviation (±5 V)* 2 C
IRIG-B 3 A
IRIG-E 4 A
IRIG-H 5 A
10 MPPS 6 A
5 MPPS 7 A
1 MPPS 8 A
100 kPPS 9 A
10 kPPS 10 A
1 kPPS 11 A
100 PPS 12 A
60 PPS* 13 A
50 PPS* 14 A
10 PPS 15 A
IRIG-D/1 PPM 16 A
1 PPH 17 A
1 PPS 18 A
Programmable Pulse 19 A
Out of Lock 20 A
IRIG-B Modified Manchester 21 A
Normal Polarity COMTRADE 22 A
Complemented Polarity COMTRADE 23 A
Table C.8: Option 23, Output Signal Selection Jumper Settings
*available in Model 1088B only
