Arbiter Systems 1084A User Manual

C.20 Option 36: Four Configurable Outputs 225
Output Signal Function Select Jumper Mode Select Jumper
IRIG-B Modulated 1 B
Deviation* 2 B
IRIG-B Unmodulated 3 A
IRIG-E 4 A
IRIG-H 5 A
10 MPPS 6 A
5 MPPS 7 A
1 MPPS 8 A
100 kPPS 9 A
10 kPPS 10 A
1 kPPS 11 A
100 PPS 12 A
60 PPS* 13 A
50 PPS* 14 A
10 PPS 15 A
IRIG-D/1 PPM 16 A
1 PPM 17 A
1 PPS 18 A
Programmable Pulse 19 A
Out of Lock 20 A
IRIG-B Mod. Manch. 21 A
No Connection 22 A
Table C.16: Option 36 Output Connector Jumper Settings
*Not available on the Model 1084A/B/C.
NOTE: If any of the jumpers were changed, replace the cover to the chassis before returning to
service.
