b. CAN Boards
NOTE:
The i2000SR IM Master Tag Reader board in the Electronic
Box(s) is not listed. Only Track CAN bus boards are listed.
For each Track CAN bus boards Address Parameter:
• A indicates the antenna connected to CN12 of the Tag
Reader board.
• B indicates the antenna connected to CN13 of the Tag
Reader board.
c. Track Layout
• Use the ¿À arrows to select the Instrument # Gate of the
i2000SR.
• In the following fields, use the
arrows to select the
desired queue parameter.
Instrument Gate
QUEUE
Instrument # Gate (i2000SR Instrument #)
NEXT QUEUE
Instrument #+1 Gate (Next Instrument) or instrument # is the
last instrument, enter the next module diverter gate.
NOTE:
Typically the next module is the Recapper. Select the
Recapper Diverter Gate
ALTERNATIVE NEXT QUEUE
Return/Entry Gate (Instrument #)
QUEUE LENGTH
8
Sampling Gate
QUEUE
Sampling Gate # (i2000SR Instrument #)
NEXT QUEUE
Return/Entry Gate (Instrument #)
ALTERNATIVE NEXT QUEUE
Not Connected
QUEUE LENGTH
