Service Manual i2000SR interface module
625798100.APS.5.doc Page 75 of 212
10
Return/Entry Gate
QUEUE
Return/Entry Gate # (i2000SR Instrument #)
NEXT QUEUE
Instrument #+1 Gate (Next Instrument) or instrument # is the
last instrument, enter the next module diverter gate.
NOTE:
Typically the next module is the Recapper. Select the
Recapper Diverter Gate
ALTERNATIVE NEXT QUEUE
Not Connected
QUEUE LENGTH
8
NOTE:
After the i2000SR IM Gate Queues lengths are changed, the
change will not take affect until the i2000SR IM power has
been cycled.
