Error Handling
Fault Handling
When closing the Error pop-up window (Fig. 5-1 Error pop-up window), a red information bar
will appear (see Fig. 5-3 Error information bar, Table and Fig. 5-4 Error information bar,
Wallstand).
60˚
60˚
cm
110
ms
20
mA
250
kV
50
Density
1
+
post mAs
58
mAs
AEC
DoB 1977-03-06
ID 987-65-4320
Hand AP
Age 36 Sex F
Acc No 987-65-4320
Jane Doe
SID
Fault message: Checksum error
X
Fig. 5-3 Error information bar, Table
ms
20
mA
250
kV
50
Density
1
+
post mAs
58
mAs
AEC
60˚
60˚
cm
110 DFD
Jane Doe ID 987-65-4320
Knee PA
Fault message: Checksum error
Fig. 5-4 Error information bar, Wallstand
When the user pushes the red information bar, the Error pop-up window will appear again.
The Error information bar (lower part of the window) is present until the error is fixed or the
System is restarted.
ARCOMA AB 1000-095-051-EN Rev. 1.1
Operation Manual
SWEDEN Page 136 2020-06-16
