8.Resistance value of charge coil
.Remove the corresponding connector of charge
coil from cable.
.Connect the multimeter(¦¸¡ Á100 ) to wire end
of charge coil
Multimeter pen (+)¡úyellow/green wire end¢Ù
Multimeter pen (-)¡úyellow/green wire end¢Ú
Coil resistance value
At 20¡æ(68¡ãF)450~550¦¸
Inspect if the resistance value conform to speci-
fication
Not conforming to specification
Replace charge coil
Connect the ignition system correctly
Poor connect
replace CDI assy
Correct
Conforming to specification
- 120 -
