ATV 200 - Page 125

.Inspect if the resistance of primary coil con-
forms to specification
.Inspect if the secondary coil resitance conforms to
specification
Primary coil resistance
At20¡æ(68¡ãF)0.43~0.5 ¦¸
Secondary coil resistance
At 20¡æ(68¡ãF)4.6-7.6K ¦¸
All conform to specification
Normal
Normal
6.Main switch
Refer to “Check switch”
5.Engine stop switch
Refer to “Check switch”
7.Resistance value of triggering coil
.Remove CDI magneto connector from cable
.Connect the multimeter(¦¸¡ Á100 ) to wire end of
triggering coil
Multimeter pen(+)¡úblue wire end¢Ù
Multimeter pen(-)¡úblue wire end¢Ú
.Inspect if the resistance of triggering coil conforms
to specification
Conforming to specification
Resistance value of triggering value:
At 20¡æ(68¡ãF)180~220¦¸
Replace triggering coil
Not conforming to specification
Abnormal
Replace main switch
Abnormal
Not conforming to specification
Replace ignition coil
Replace handlebar switch (left)
.Connect the multimeter£¨¦¸¡Á1K£©to ignition coil
