29.Remove
.Main shaft assy and driving shaft unit
.Washer(driving shaft unit)
30.Remove
.Circlip
.Balance shaft driving gear
.Crankshaft
.Semicircle key
.Press out the crank shaft with pressure device.
31.Remove
.Stop plate
.Pressing plate
Knock the locking part of stop plate flat be-
fore removing the stop plate.
32.Remove
.Distribution cam shaft
.Screw in the bolt 10mm to cam shaft screw
hole to draw out the distribution cam shaft.
Caution
Caution
Caution
- 153 -
