33.Remove
.Valve lock clip
.Disassemble the valve lock clip with valve
spring compressing device.
34.Remove
.Valve spring cover
.Valve outer spring
.Valve inner spring
.Valve
.Oil seal of valve rod
.Spring seat of valve
.Pay attention to position of each component
for installation to original position.
35.Remove
.Starting lever cap
.Starting lever
.Before uniting the knot,pull out the rope long
enough to tie a knot to avoid to be pulled into
the cap
36.Remove
.Screw pin
.Guide plate
.Compressing spring
.Circlip
.Driving jaw
.Torsion spring
Caution
Caution
Caution
37.Remove
.Pressure plate
.Remove the screw with impact screwdriver
38.Remove
.Bearing
.Washer
39.Remove
.Circlip
.Rear joint
Caution
- 154 -
